HELIX CONDUCTOR is ACO remote controller<br>
<br>
FEATURES:<br>
Up to 4 individual volume menus configurable<br>
(Master, Digital, HEC/AUX, Subwoofer, Rear Att.)<br>
• Volume range selectable (60 dB, 24 dB, 12 dB).<br>
• Volume steps selectable (1 dB steps, 0.5 dB steps).<br>
• Individual color for each volume menu configurable.<br>
Sound Setup selection between all 10 memory slots.<br>
Intuitive Bluetooth playback control and pairing activation<br>
(only for Bluetooth Extension Card).<br>
12 x RGB-LEDs for visual feedback.<br>
• Wide color space with over 16 million colors.<br>
• Brightness and automatic dimming function<br>
configurable.<br>
Easy installation.<br>
• Flush mount installation with Ø 40 mm hole cut-out.<br>
• 5 m cable harness with split connector and single<br>
connector supply.<br>
• Optional housing for on-dash installation available<br>
soon.<br>
Full configuration and updatability through the DSP PC-Tool software.<br>
DSP PC-Tool 4.75a or higher.<br>
<br>
COMPATIBILITY:<br>
BRAX DSP<br>
HELIX DSP ULTRA<br>
DSP.3<br>
DSP MINI<br>
V TWELVE DSP<br>
V EIGHT DSP MK2<br>
MATCH M 5DSP MK2<br>
<br>
Note: The CONDUCTOR is not compatible with the WIFI CONTROL or the DIRECTOR.<br>
<br>
Note 2: The CONDUCTOR is not compatible with UP 7DSP / UP 7BMW

TECHNICAL DATA

Housing: ABS housing with machined aluminum knob.
Hardware: Rotary encoder, 12 x RGB-LEDs &
48 MHz ARM processor.
Connection: Single connector supply through
MiniDIN or NanoFit.
Cable length: 5 m total length – split into 4.8 m connection cable + 0.2 m CONDUCTOR cable.
Dimensions: (Ø x H) Ø 46 x 28.7 mm /
Ø 1.81 x 1.13”.
