<p>A step into the future with a tribute to the past. Meet our game-changing wireless turntable designed for a new generation of audiophiles. Featuring MusicCast multi-room capabilities, share the joy of your record collection in any room.<br><br>Wirelessly connect to any MusicCast device for seamless listening<br>Straight tonearm contributes to sound transparency and openness<br>Belt drive turntable<br>Music streaming services built-in<br>Wi-Fi built-in including support for 2.4 GHz and 5 GHz bands</p>

TECHNICAL DATA

Network SectionFile FormatEthernetWi-FiAirPlayBluetooth SectionVersion/ProfileAudio CodecMaximum Communication RangeTurntableDrive MethodMotorRotation SpeedRotation Speed VariationWow And FlutterPlatterOutput LevelSignal To Noise RatioTonearmTonearmEffective Arm LengthOverhangStylus Pressure Adjustment RangeAcceptable Cartridge WeightAttached CartridgeCartridge TypeOutput VoltageStylus PressureCartridge WeightCartridge HeightHead-shell WeightAudio SpecificationsOutput TerminalOutput LevelSignal to Noise RatioDynamic RangeHarmonic DistortionFrequency ResponseGeneralPower ConsumptionEco-Standby (reference date)Standby Power ConsumptionDimension (W×H×D)Weight
MusicCast VINYL 500 (TT-N503)
MusicCast VINYL 500 (TT-N503)
Turntable
Network SectionFile FormatMP3 / WMA / MPEG-4 AAC: up to 48 kHz / 16-bit, ALAC: up to 96 kHz / 24-bit, FLAC / WAV / AIFF: up to 192 kHz / 24-bit, DSD: up to 11.2 MHz
EthernetYes
Wi-FiYes (2.4 / 5 GHz)
AirPlayYes
Bluetooth SectionVersion/ProfileVer. 4.2 / A2DP, AVRCP
Audio CodecSBC, AAC
Maximum Communication Range10 m / 32.8 ft. 10 in. (without interferene)
TurntableDrive MethodBelt drive
MotorDC motor
Rotation Speed33-1/3 rpm, 45 rpm
Rotation Speed Variation±2%
Wow And Flutter0.2%
PlatterAluminium die-cast (Diameter 30 cm)
Output Level450 mV (-7 dBV, with RIAA EQ, 1 kHz, 3.54 cm / sec), 2.5 mV ± 3 dBV (without RIAA EQ, 1 kHz, 3.54 cm / sec)
Signal To Noise Ratio67 dB or higher (A-weighted, 20 kHz, LPF)
TonearmTonearmStatic balance straight tonearm
Effective Arm Length223.5 mm
Overhang19 mm
Stylus Pressure Adjustment Range0-4 g
Acceptable Cartridge Weight15.5-19 g (including headshell)
Attached CartridgeCartridge TypeMM type
Output Voltage2.5 mV (1 kHz, 3.54 cm / sec)
Stylus Pressure3.5 ± 0.5 g
Cartridge Weight5.0 ± 0.3 g
Cartridge Height17.0 ± 0.7 mm
Head-shell Weight10 g (including screws, nuts and wires)
Audio SpecificationsOutput TerminalRCA: 2 (PHONO, LINE)
Output Level2.0 ± 0.3 V (1 kHz, 0 dB, Fs 44.1 kHz)
Signal to Noise Ratio[IHF-A network] 110 dB or higher (Infinity zero, Fs 44.1 kHz)
Dynamic Range100 dB or higher (1 kHz, -60 dB, Fs 44.1 kHz)
Harmonic Distortion0.003 % or lower (1 kHz, 0 dB, Fs 44.1 kHz)
Frequency ResponseFs 44.1 kHz 2 Hz to 20 kHz (+0 / -3 dB), Fs 48 kHz 2 Hz to 24 kHz (+0 / -3 dB), Fs 96 kHz 2 Hz to 48 kHz (+0 / -3 dB), Fs 192 kHz 2 Hz to 96 kHz (+0 / -6 dB)
GeneralPower Consumption6 W
Eco-Standby (reference date)0.3 W
Standby Power Consumption1.4 W (Network standby ON, Bluetooth® standby OFF, Wired), 1.8 W (Network standby ON, Bluetooth standby ON/OFF, Wi-Fi), 1.6 W (Network standby ON, Bluetooth standby ON, Wired)
Dimension (W×H×D)450 x 136 x 368 mm 17-3/4” x 5-3/8” x 14-1/2”
Weight5.7 kg 12.6 lbs..
