The ″M package″ for your BMW HiFi sound system (option 676) – The MATCH UP 7BMW is a revolutionary sound upgrade for those who desire significantly more power and dynamics, but also care about seamless integration into the vehicle.<br>
<br>
The installation is done in the blink of an eye at the mounting position of the original amplifier thanks to the included Plug &amp; Play connection cable and a custom-fit mounting plate. Nevertheless, the UP 7BMW amplifier is so flexible that it can easily be used for universal applications in BMW vehicles.<br>
<br>
Besides Audiotec Fischer′s proprietary Class HD technology and the cutting-edge 64 Bit DSP with tremendous processing power, new and high innovative DSP features such as ″Augmented Bass Processing″, the ″StageXpander″ and the “RealCenter” function guarantee top-class listening pleasure.<br>
<br>
Of course, the UP 7BMW also offers a MATCH Extension Card slot (MEC slot) for additional input and output modules such as a Bluetooth Audio Streaming module or a High Resolution audio USB sound card.<br>
<br>
Thanks to the professional and user-friendly DSP PC-Tool software V4 the configuration of the UP 7BMW becomes straigthforward and intuitive.

TECHNICAL DATA

Fits to ALL BMW-model ranges with HiFi Sound System ( option 676 )

Output power RMS / max.
– @ 4 Ohms5 x 65 / 130 Watts (Front / Rear / Center channels)
– Subwoofer output @ 2 Ohms2 x 160 / 320 Watts
Amplifier technologyClass HD

4 x Highlevel speaker input
1 x Optical SPDIF (12 – 96 kHz)
1 x MEC
1 x Remote In
Input sensitivityHighlevel 2.0 – 8.3 Volts
Input impedance highlevel13 Ohms

7 x Speaker output
1 x RCA output
2 x Remote Out
Output voltage RCA3 Volts RMS

Frequency response20 Hz – 22,000 Hz
DSP resolution64 Bit
DSP power295 MHz (1.2 billion MAC operations/second)
Sampling rate48 kHz
DSP typeAudio signal processor
A/D-converters: BurrBrown
D/A-converters: BurrBrown
Signal-to-noise ratio digital input105 dB (A-weighted)
Signal-to-noise ratio analog input103 dB (A-weighted)
Distortion (THD) 0.03 %
Damping factor 100
Operating voltage10.5 – 16 Volts (max. 5 sec. down to 6 Volts)
Current draw450 mA
Max. remote output current500 mA

Fuses2 x 25 A LP-Mini-fuse (APS)
Class HD technology with dynamically controlled
power supply
ADEP.3 circuit
Start-Stop capability
Control Input ( URC, Director )
USB ( for PC control only )
MEC slot
Auto Remote switch
Galvanically isolated Line Out

Dimensions (H x W x D)46 x 130 x 153 mm.
