TECHNICAL DATA

MOST Interface to Mercedes- Benz, BMW, AUDI, Porsche, VW Land Rover and Volvo Compatibility: AUDI A4, A5, A6, A8, Q5, Q7 (MMI 2G, 3G) with separate external amplifier AUDI A4, A5, A6, A8, Q5, Q7 (MMI 3G+) Compatibility: BMW E60, E61, E63, E64, E70, E71, E72, E90-E93. BMW F01, F02, F03, F07, F10, F11, F12, F13, F16, F20, F25, F30, F31, F34. BMW G-series BMW E65, E66 Compatibility: Land Rover Freelander 2 Land Rover Freelander 2 (HSE) Land Rover Discovery-3, Discovery-4 until 2013, Range Rover Sport until 2012. Range Rover Evoque, Range Rover Sport 2012+, Compatibility: Mercedes Benz until 2009 (NTG1 audio systems without external unit the AGW and NTG2). Mercedes Benz (NTG1 audio system with the external unit AGW) – W211, W219, W220. Mercedes Benz (NTG3 and NTG3.5 audio systems, audio systems with AGW block the production of Becker). Mercedes Benz 2008+ (NTG2.5, NTG4, NTG4.5 audio systems). Compatibility: Porsche until 2009 (Cayenne, etc. with PCM2.0 and PCM2.1). Porsche 2009+ (Cayenne, etc. with head unit PCM3.0) Compatibility: Volvo S80, XC70, V70 until 2012, Volvo V70, XC70 2012+ and some models Volvo S60, V60 Volvo S60, V60 Volvo XC60 Premium Volvo XC90, S40, V50. The standard phone module is not supported. Dimensions adapter: 90 х 60 х 25 mm Power supply voltage: 8 … 16 volts Current consumption in sleep mode: less than 0.5 mA Digital output: SPDIF / TosLink Sound Processor: 24 bit Dynamic range: no less than 100 db Package incl. Power cable Jumpers – 3pcs Quick guide Depending on vehicle specification, possibly additionally required (sold separately): Optical cable (0,8m) with connector for system MMI 3G+ (Audi or VW Touareg NF). for BMW or MB (if original amplifier is missing). for Volvo (during the procedure «serial number assignment»), Only optical connector for BMW or MB (if the original amplifier is present). Notes for BMW and Mercedes Benz (If the optical amplifier Logic-7 is not in the original vehicle specification): It is necessary to register in the configuration of the vehicle using the diagnostic equipment, To connect the adapter, you will also need an optical cable with connector (not supplied). Notes for BMW: an additional mode of the adapter (BMW spec.mode (park)). This mode should be used if you want to change the volume of the signal (parking sensors and system messages). Read more about this mode in the Applications. Notes for Mercedes Benz (only for Comand NTG2.5): – It is necessary to activate function “Rearseat entertainment”. Notes for Volvo and Land Rover (if you have activated component protection): Before connecting the adapter must be assigned to the adapter serial number (a marker of activity of the protection components is the cessation of broadcast audio adapter in 20-40 seconds after turning on the system). For the assignment you need to set the jumpers to position «Read Serial Number», then, not disconnect the original amplifier, connect the adapter to the optical interface MOST and turn on audiosystem. After you enable the adapter «read» the serial number of original amplifier and store it in its non-volatile memory. This procedure usually takes less than 20 seconds, a sign of the end of the procedure «Read Serial Number» is the formation of pulses with an interval of 1 second on the line Remout (blue wire). After that you should disable original amplifier, set the jumpers to a position corresponding to the car and use the audio interface in the system instead of the original amplifier.
