Uranium-SQ amplifier with absolute high end sound quality. These models have received top class ratings in a german car audio magazine.

TECHNICAL DATA

– 2 Ohm stable stereo
– Adjustable BIAS control (for each pair of channels separately)
– High End WIMA® Capacitors
– Latest BURR-BROWN® operational amplifiers
– Status LED
– Wide-band adjustable high pass & low pass filters
– Band-pass feature with activated LPF & HPF
– Adjustable input sensitivity
– Soft delayed remote turn on
– Thermal / speaker short circuit / overload / over current protection
– Temperature sensor controlled cooling fan

Output Power @ 4 Ohm (CEA*)4x 110 W + 2x 160 W
Output Power @ 2 Ohm (CEA*)4x 160 W + 2x 280 W
Bridge mode @ 4 Ohm (CEA* / 10% THD)2x 380 W + 1x 640 W

Lowpass20 – 400 Hz / 200 Hz – 4000 Hz (x10)
Highpass20 – 400 Hz / 200 Hz – 4000 Hz (x10)
Bandpass20 – 4000 Hz

Dimensions cm 20.9 x 4.6 x 55.0 cm.
