<p>1.1″ sound quality silk dome tweeter<br><br>28 mm / 1.1″ silk dome tweeter<br>Flush mount housing<br>Coated silk dome<br>Gold plated connectors<br>Neodymium motor<br>Connection wires<br>1 pair / package</p>

TECHNICAL DATA

Model
Silk dome tweeter

Diameter
28 mm / 1.10″

Power Handling (RMS/max.)
80 / 130 Watts

Impedance
4 Ohms

Efficiency
90 dB

Frequency Response
2500 Hz – 25 kHz

Empfohlener Hochpass-Filter
3000 Hz @ 12 dB/oct

Voice Coil
28 mm / 1.1″

Membran Layout
Coated silk dome

Mounting Ø
48 mm / 1.89″

Mounting Depth
18 mm / 0.71″

Resonance Frequency (Fs)
1300 Hz

(Installation tip: The wire with a white stripe is the plus cable).
