DD Audio AT-28a PRO

179.00
people are viewing this right now

DD Audio new AT-28a PRO tweeter

Prekės prieinamumas: klausti
Klausti







      Image Safe Checkout
      Garantuotas saugus apmokėjimas
      • NEMOKAMAS PRISTATYMAS LIETUVOJE UŽSAKIUS VIRŠ 99 EUR
      • PREKIŲ PRISTATYMAS LIETUVOJE PER 2 - 3 D.D. Shipping & Return

      <p>The New AT-28a PRO is a new design that offers a soft rich sound with extraordinary detail and excellent off axis response. This 1.1” natural silk dome coupled to a high roll surround is ultra light for both higher sensitivity and extended frequency bandwidth. The dome is driven by a copper clad aluminum ribbon wire voice coil wound on a titanium former in an underhung magnet gap. This ultra light and rigid structure passes energy without distortion.<br><br>The diaphragm system is driven by a powerful neo magnet motor with copper shorting ring. The motor is mounted in a dual balanced compression chamber improving the transient dynamics over a broad bandwidth. The internal flow optimized vents and baffles eliminates standing waves between the chambers and couples the air masses together, and in combination with the high roll surround, allows an ultra low Fs of 675 Hz. The laser etched backplate and large hex pattern grill aesthetically finishes off this sonically stunning driver.</p>

      TECHNICAL DATA

      Features
      1.1” Natural Silk Fiber Dome
      Titanium Alloy Voice Coil Former
      Copper Clad Aluminum Ribbon Wire Voice Coil
      Neodymium Motor
      Dual Chamber Tuned Rear Cavity
      Copper Shorting Ring Design
      Laser Etched Back Plate
      Gold Plated set Screw Terminals
      Smooth Frequency Response From 3kHz – 25kHz

      Speaker Size (MM): 28
      Watts RMS: 50
      Watts Peak: 125
      Impedance: S4
      VCD (MM): 28
      Frequency Response (Hz): 1500 – 25k
      Fs (Hz): 675
      dBSPL: 91.2
      Mounting Diameter (In): 1.6
      Mounting Diameter (MM): 40.6
      Mounting Depth (In): 0.67
      Mounting Depth (MM): 17

      Gamintojas

      DD Audio
