<p>Raggarplanka Amplified includes GZCB 16.2SPL Fullrange SPL speakerbox + Powerful and exceptionally high-quality AI-SONIC S2-A150.2 amplifier.<br><br><br>GZCB 16.2SPL:<br><br>GZCB 16.2SPL Fullrange SPL speakerbox!<br><br>LOUD enclosure with 4 GZCK 165XSPL midbasses<br>and 2 GZCT 25SQL tweeters. There are terminals on the side of the case,<br>so all you have to do, is plug in the speaker cords and you can start enjoying<br>about music!<br><br>Free placement! You can put the enclosure wherever you want.<br>For a hat rack, camper, trunk, or lift though<br>on the roof as a party booster!<br><br><br>S2-A150.2:<br><br>AI-Sonic S2-A150.2 is 2-channel AB class amplifier for users, who want to feel pure sound quality.<br>Amplifier gives more power as there are mentioned at the specs.<br><br>Finished dark cover, which profile is brushed black aluminium.<br>When amplifier is on. There is indicator light in AI-Sonic logo!<br><br>Includes a remote control, which has three different indicator-leds.<br>(protection, power and clipping)<br><br>Designed in Finland.<br><br>(Bass level control sold separately and it works only when LPF is turned on.)</p>
TECHNICAL DATA
GZCB 16.2SPL
High-power loudspeaker enclosure
2-way loudspeaker system Full range audio reproduction
Klippel® optimized
High efficiency (SPL)
6.5″ double-midwoofer (GZCK 165XSPL)
1″ silk dome tweeter (GZCT 25SQL)
12 dB/oct crossover
Solid enclosure made from MDF
GZ design push terminal
Owner′s manual enclosed
Specifications:
Frequency response: 50 Hz – 22 kHz
Impedance: 2x 2 ohms
Efficiency: 93 dB
Power handling (stereo) 2x 200 W RMS (@ 2 ohms) 4x 400 W max (@ 2 ohms)
Power handling (serial) 1x 400 W RMS (@4 ohms) 1x 800 W max (@4 ohms)
Dimensions (straight dispersion) 35.43″ x 11.81″ x 9.65″ / 90 x 30 x 24.5 cm (wxhxl)
Dimensions (angled dispersion) 35.43″ x 8.66″ x 11.81″ / 90 x 22 x 30 (wxhxl).
S2-A150.2
RMS POWER (2ohm) 12v 1%THD 2x225W
RMS POWER (4ohm) 12v 1%THD 2 x 150W
BRIDGED POWER(4ohm) 12v 1%THD 1 x450W
T.H.D 0,02% 4ohm, 0.04 % 2ohm
BANDWIDTH: 10Hz-40KHz
S/N RATIO (A-WEIGHTED): 105dB
CHANNEL SEPARATION: 45dB
INPUT SENSITIVITY :0.5-6V
LOW PASS x1: 50Hz- 500Hz x10: 500Hz-5KHz
HIGH PASS x1: 12Hz-250Hz x2Q: 250Hz-5KHz
BAND PASS(FRONT ): 12Hz- 5KHz
CROSSOVER SLOPE: 12dB/oct
BASS BOOST: 0/6dB(@45Hz)
POWER FUSE: 2 x 30A
HIGH-LEVEL VOLTAGE: 0.75-9V
Cable fitting size:
+12V = 20mm2
GND = 20mm2
REM = 6mm2
SPEAKER = 6mm2
Current Draw (Max): 52A
DIMENSIONS W: 183mm / (7.2 IN)
H: 60mm / (2.4 IN)
L: 374mm / ( 14.7IN).
