<p>The premium sound upgrade for 24 Volts multi-channel factory systems<br>The new UP 10DSP – 24V Edition is a real problem solver for upgrading sound systems in trucks and buses, especially thanks to its 24 Volts capability. Even though more and more vehicles are equipped with complex multi-channel sound systems ex works, the sound quality does not always meet one′s expectations.<br>In many cases, a replacement is no longer possible, so that only an amplifier with a large number of highlevel inputs and sophisticated technology can be considered for upgrading the system. And here the new UP 10DSP – 24V Edition offers the perfect solution.<br><br>Maximum connectivity<br>For optimal adaptation to existing multi-channel sound systems, the UP 10DSP – 24V Edition is equipped with not less than 8 highlevel inputs (two high power inputs with up to 32 Volts), an optical digital input, a MATCH extension card slot, 10 amplifier outputs and a total of 11 processed DSP channels.<br>In addition, intelligent technologies, such as the proprietary ADEP.3 circuit and 32 Bit ACO platform, ensure safe operation.<br><br>Virtual Channel Processing – that´s how signal routing works today<br>The adaptation to modern OE sound systems via an increasing number of inputs has a significant impact on the complexity of the signal routing inside the amplifier. Especially when several input signals are mixed together and then split again into multi-way systems, conventional routing concepts quickly reach their limits, both in terms of implementation and usability. Audiotec Fischer′s new multi-stage ″Virtual Channel Processing″, in conjunction with the recognized user-friendly DSP PC-Tool software makes it easy to realize even highly complex system configurations. Besides, it allows to freely assign our proprietary FX sound features such as ″RealCenter″ or ″Augmented Bass Processing″. But the UP 10DSP – 24V Edition, thanks to its enormous number of channels in combination with the optional MEC ANALOG IN module, is also a prime example for applications where 1 to 1 routing (IOR) makes sense.<br><br>Speed is everything – thanks to ACO<br>Such a huge number of channels requires ultra-fast hardware – Audiotec Fischer′s proprietary 32 Bit ACO platform takes care of all control tasks and ensures the decisive speed increase, especially for data communication with our DSP PC-Tool software but also for the lightning-fast switching between up to ten sound setups. But ACO offers much more – fantastic sound effects such as Augmented Bass Processing or RealCenter are implemented as well as a channel-separated Input EQ including the Input Signal Analyzer (ISA) for easy analysis and compensation of input signals of OE radios.<br><br>Powerhouse in a compact format<br>Despite its huge output power of 8 x 65 Watts at 4 Ohms and 2 x 90 / 160 Watts at 4 / 2 Ohms at the Sub Outs, as well as the enormous feature set, the UP 10DSP – 24V Edition comes in an extremely compact design, so that installation is possible even in confined spaces.</p>

TECHNICAL DATA

Compatibility:
Only for operation on 24 Volts vehicle electrical systems!

Technical data:

UP 10DSP – 24V Edition
Output power RMS
– @ 4 Ohms Channels A – H: 8 x 65 Watts
– @ 2 Ohms –
– @ 1 Ohm –
– bridged @ 4 Ohms –
– bridged @ 2 Ohms –
– Subwoofer output @ 4 Ohms Channels I – J: 2 x 90 Watts
– Subwoofer output @ 2 Ohms Channels I – J: 2 x 160 Watts
Amplifier technology Class GD
Inputs 8 x Highlevel speaker input
1 x Optical SPDIF (12 – 96 kHz)
1 x Remote In
Input sensitivity Channels A – F: 4 – 16 Volts
Channels G – H: 4 – 16 or 8 – 32 Volts
Input impedance RCA / Cinch –
Input impedance highlevel 9 – 33 Ohms with ADEP.3
Outputs 10 x Speaker output
1 x RCA / Cinch
1 x Remote Out
Output voltage RCA / Cinch 3 Volts
Frequency response 10 Hz – 22,000 Hz
DSP resolution 64 Bit
DSP power 295 MHz (1.2 billion MAC operations/second)
Sampling rate 48 kHz
DSP type Audio signal processor
Signal converters A/D: BurrBrown
D/A: BurrBrown
Signal-to-noise ratio digital input 105 dB (A-weighted)
Signal-to-noise ratio analog input 103 dB (A-weighted)
Distortion (THD) 0.03 %
Damping factor 100
Operating voltage 18 – 36 Volts (max. 5 sec. down to 12 Volts)
Power rating DC 24 V ⎓ 32 A max.
Idle current 210 mA
Max. remote output current 500 mA
Operating temperature range -40° C to +70° C
Fuse 2 x 25 A LP-Mini-fuse (APS)
Additional features Class GD technology with dynamically controlled
power supply, 32 Bit CoProcessor, ADEP.3 circuit, Start-Stop capability, Smart Control Port, USB, MEC slot, Auto Remote switch, galvanically isolated Line Out
Dimensions (H x W x D) 46 x 145 x 163 mm /
1.81 x 5.71 x 6.42″

Scope of delivery:

1 x MATCH UPGRADE amplifier UP 10DSP – 24V Edition
2 x Connection cable
1 x Mounting plates & material
1 x USB cable
1 x Instruction manual
