High sound quality and sophisticated design based on Yamaha’s rich experience and high-end model concepts. A HiFi Amplifi er for enjoying excellent sound. Yamaha high sound quality, created by rich experience and tradition, and high technological expertise Pure Direct Mode for greater sound purity Simple and sophisticated design Phono MM terminal for vinyl playback Screw-type speaker terminals Speaker selector and speaker terminals for two systems Simple design remote control Head phone terminal

TECHNICAL DATA

Minimum RMS Output Power (8 ohms, 40Hz～20kHz) 100 W + 100 W (0.2% THD)

Maximum Power (4 ohms, 1kHz, 0.7% THD, for Europe) 115 W + 115 W

High Dynamic Power/Channel (8/6/4/2 ohms) 125 W/150 W/165 W/180 W

Frequency Response 20Hz-20kHz (0+/-0.5db), 10Hz-100kHz (0+/-3.0db)

Total Harmonic Distortion (8 ohms, 20 Hz-20 kHz) 0.025%
(Phono (MM) to REC Out), 0.2% (CD to SP Out)

Signal-to-Noise Ratio (CD) 100 dB (S: 500 mV)

Input Sensitivity (CD) 500 mV / 47 k-ohms

Standby Power Consumption 0.5 W

Weight 6.7 kg
