A-50DA Pure Audio Full Amplifier/Converter with 2×90 Watts, Phono and asynchronous USB Digital Input

Open to all possibilities

The A-50DA is open to all current end music formats Its high-grade phono input deals with the signals from record players, while four golden cinch inputs are ready for all types of Players. Digital formats are dealt with by a highly modern D/A converter based on the ESS SABRE Ultra. Via asynchronous USB transfer this converter also supports ultra-high-resolution material with 32 bit and up to a sampling rate of 384 kHz, as well as native DSD with up to four times the rate (11.2 MHz). The switch output stages in the A-50DA specially developed for use with music supply 90 watts per channel; a mains transformer of large dimensions with separate windings for the power amplifier, pre-amplifier and controls ensure a stable feed, including with highly-dynamic encoded material. A thick aluminium front panel, metal knobs, massive screw terminals and, last but not least, a high-grade remote control ensure that everyday use of the A-50DA will provide as much enjoyment as its sound.

AUDIO FEATURES

90 W + 90 W (20 Hz-20 kHz, THD 0.5 %, 4 ohms)

65 W + 65 W (20 Hz-20 kHz, THD 0.5 %, 8 ohms)

THD: 0.02 % (Rated Output -3 dB, 8 ohms, 1 kHz)

Guaranteed Speaker Impedance: 4-16 ohms (A or B), 8-32 ohms (A+B), 4-16 ohms (Bi-Wiring)

Frequency Response (Measured with DIRECT button switched on): SACD/CD, NETWORK, LINE1, LINE2 5 Hz-50 kHz, ±3 dB

RIAA Deviation: PHONO MM 20 Hz-20 kHz, ±0.5 dB

Signal-to-Noise Ratio (IHF, A Network, Short Circuited)

SACD/CD: 101 dB, Phono: 89 dB (MM: 5 mV input)

Power Amp Direct: 110 dB

Channel Separation

SACD/CD: 90 dB (100 Hz), 84 dB (1 kHz), 75 dB (10 kHz)

Power Amp Direct: 95 dB (100 Hz), 95 dB (1 kHz), 80 dB (10 kHz)

Pure Audio Grade High Efficiency Power ›› MOSFET Amplifier (Class D Amplifier)

Separated Construction for Preamp and Power Amp

Isolated Power Supply

Source Direct Mode

Highly Acclaimed ESS SABRE32 Ultra DAC

384 kHz/32-bit USB-DAC for Asynchronous Transfer

Trans-Stabilizer

Speaker A, B, A+B Selector

OPERATING FEATURES

Aluminium Front Panel and Rotary Knob

Auto Power Down

Hair Line Finish Remote Controller

CONNECTIONS

Exclusive Gold-Plated Speaker Terminals (Large Type)

Gold-Plated Analogue Audio Input (Phono MM, CD, LINE 1, LINE 2, NETWORK, USB, COAXIAL, POWER AMP DIRECT IN)

USB Input for Asynchronous Transmission

Digital Coaxial Input

Digital Optical Input

Audio Output (LINE 2, PHONES)

SR In/Out

AC Inlet (Large Type)

DIMENSIONS & WEIGHT

Dimensions (W x H x D): 435 x 138.5 x 357 mm

Weight: 11.2 kg
