Tube amplifier hand-made construction with the finest point-to-point wiring.

Two EI output transformers with wide bandwidth are applied.

Specially designed toroid transformer for power supply.

One piece of 12AU7 and two pieces of 6N1 are used in the Preamplifier stage: 12AU7 for voltage amplification and 6N1 for drive amplification.

Four EL84EH tubes are used for AB1 push-pull amplification.

High-quality Japanese ALPS potentiometer.

Equipped with easily-installed tube cover for protection.

Power Output                                     10W+10W

Frequency Response                         9Hz~45kHz (-3dB)

THD                                                    0.5% (1kHz)

S/N Ratio                                            87dB

Input Sensitivity                                  230mV

Input Impedance                                100kΩ

Output Impedance                             4Ω～8Ω

Max Power Consumption                   80W

Tube                                                   12AU7 1、6N1 2、EL84EH 4

W D H                                                 330×245×160mm³

Net Weight                                          8.3kg

Working Condition                              Temperature 0°C~40°C      Moisture 20%~80%

Storage Condition                        Temperature -20°C~70°C      Moisture 20%~90%
