Stunning Realism, Immersive Sound

The AVR20 is a high-performance audio/visual receiver that delivers stunning realism for the ultimate home cinema experience. With an impressive 16-channel surround solution and featuring all the latest CODECs from Dolby, DTS, Auro-3D and IMAX Enhanced, the AVR20 exemplifies sound quality and engineering excellence.

The AVR20 features the efficient class AB amplification for a level of transparency that delivers the most captivating sound. Audiophile listening experiences are optimised with full 16-channel Dirac calibration on board as well as simple streaming with a mobile device using the native app of choice via Apple AirPlay2 or Google Chromecast.

Dirac Live® Bass Control aggregates measurement and location data from each subwoofer as well as the main speakers to determine how a system’s bass is distributed throughout the room.

Specifikacija

7.1.4-ch AVR Class A/B
• Entry premium multi-channel audio video receiver
• Powerful Dolby Atmos & DTS:X object-based DSP
• Dirac Live automatic room correction system
• HDMI 2.0 (UHD) w/ HDCP 2.2 (incl. Zone 2)
• 7 channels of integrated class A/B amplification designed to drive
low impedance loads
• Automation via IP, RS-232, 12V trigger and IR
• 2 channels: 85 WPC at 8Ω
• 7 channels: 60 WPC at 8Ω
• Add 4 channels of amplification for full 7.1.4
• Same features and specifications as AVR30, except class A/B power.
Uses frame-type transformer
• Automation via IP, RS232, IR & 12V trigger
• Google Cast/UPnP capability for streaming audio
• Wifi / Ethernet & Bluetooth
• Weight: 36.3 lbs (16.5kg)
• Dimensions W x D (including speaker terminals) x H (including feet):
433 x 425 x 171mm
• Packaged weight: 43.6 lbs (19.8kg)

• Dolby Atmos , IMAX Enhanced, Auro-3D & DTS:X 9.1.6 decoding
• 4K (UHD) HDMI2.0b with HDCP2.2
• 7 HDMI inputs, 3 HDMI outputs, eARC compatible
• Dirac Live® for Arcam room correction
• ESS 9026PRO audiophile DAC
• Class AB power amplification – Uses toroidal transformer
• Wifi / Ethernet, RS232 and IR control
• Google Cast/UPnP capability for streaming audio
• Roon Ready Certified
• MQA supported
• Bluetooth
• Free MusicLife iOS UPnP and control app
