DESIGN

The Jamo S 62 CEN center channel speaker makes an outstanding choice for the ideal cinematic experience or the best in multi-channel sound. Available in White Ash, Dark Apple or Black Ash the S 62 CEN can be wall-mounted via keyhole mounts or placed on a video shelf. The front fabric grille is easily removable, allowing you to decide which look you prefer. The S 62 CEN is the perfect matching center channel speaker for the entire Studio 620 Series.

TECHNOLOGY

1-inch (25 mm) soft dome tweeter/dual 4-inch (102 mm) aluminized woofers.

Bass-reflex design with flared, rear-firing port: Increases speaker efficiency and bass output.

Waveguide: A unique tweeter faceplate that provides more uniform dispersion in the critical frequency range of 2-10 kHz. Dynamics and clarity are enhanced while distortion is significantly reduced.

Centre-plug: Replaces the typical dust cap and eliminates cone breakup, for a woofer with faster “attack” and tighter, more natural bass.

Aluminized woofers: Increase driver cone rigidity for solid bass reproduction.

Magnetically shielded: Placement near a legacy “CRT” TV will not distort its picture.

5-way binding posts: Allows for multiple connection options with wire up to 12 gauge (AWG).

SPECIFICATIONS

System Type   2 Way Bass Reflex

Impedance   6

Weight (Kg/lb)   5.2 / 11.5

Tweeter (mm/in)   25 / 1

Woofer (mm/in)   Dual 102 / 4

Product dimensions (mm/in, HxWxD)   133 x 400 x 210 / 5.2 x 15.7 x 8.3

Frequency Response (Hz, +/-3dB)   75-20,000

Power Handling (Watts Long/Short Term)   80 / 130

Sensitivity (dB, 2.8V/1m)   87

Crossover Frequency   2500

Finish   Black Ash , White Ash
