<p>Experience Power in Simplicity with Pioneer DMH-AF555BT. Equipped with Pioneer’s signature specifications, Pioneer Sound Tuning Features, an immersive infotainment system and seamless smartphone connectivity powered by WebLink®, we give you the freedom to experience enhanced in-car entertainment on your terms with the touch of a fingertip. Just touch, customize, and repeat.<br><br>9″ Large Screen Display<br>Easy-To-Use High-Quality Capacitive Touch Screen<br>Pioneer Bass Boost<br>Pioneer Sound Tuning Features<br>Built-in 4x50W Amplifiers<br>Immersive Infotainment System Powered By WebLink®<br>Seamless Smartphone Mirroring With WebLink® Cast<br>Navigate With WebLink<br>Weather Update With WebLink<br><br>Back-Up Camera Ready (Camera sold separately)</p>

TECHNICAL DATA

Display
9.0” WSVGA Full Flat Display – Floating Design

DIN Size
2-DIN

WebLink ® Infotainment System
Yes

Pioneer Bass Boost
Yes

Pioneer Crossover Setting
Yes

Pioneer Equalizer
Yes

Back-Up Camera Ready
Rear camera input

Bluetooth
Yes (AVRCP 1.6)

USB Interface
1 x USB Interface supporting Full HD playback and 1.5A Quick Charge

AUX Input
Rear

Audio Format
WMA / MP3 / WAV / AAC / FLAC

Video Format
H.264 / MPEG4 / WMV

Audio Output (RCA)
1 system x front, 1 system x rear, 1 system x subwoofer

(13-Band Graphic Equaliser):
Frequency: 50 Hz/80 Hz/125 Hz/200 Hz/315 Hz/ 500 Hz/800 Hz/1.25 kHz/2 kHz/3.15 kHz/5 kHz/8 kHz/12.5 kHz Gain: ±12 dB (2 dB/step)

HPF: Frequency: 25 Hz/32 Hz/40 Hz/50 Hz/63 Hz/80 Hz/ 100 Hz/125 Hz/160 Hz/200 Hz/250 Hz

Subwoofer/LPF: Frequency: 25 Hz/32 Hz/40 Hz/50 Hz/63 Hz/80 Hz/ 100 Hz/125 Hz/160 Hz/200 Hz/250 Hz

Bass boost: Gain: +12 dB to 0 dB (2 dB/step)

Mounting Dimension
(W) 178mm x (H) 100mm x (D) 110mm
