Match UP 10DSP

999.00 vnt
people are viewing this right now

Ultra efficient 10-channel amplifier with 1-channel line output and 11-channel DSP

Prekės prieinamumas: klausti
Klausti







      Image Safe Checkout
      Garantuotas saugus apmokėjimas
      • NEMOKAMAS PRISTATYMAS LIETUVOJE UŽSAKIUS VIRŠ 99 EUR
      • PREKIŲ PRISTATYMAS LIETUVOJE PER 2 - 3 D.D. Shipping & Return

      <p>Ultra efficient 10-channel amplifier with 1-channel line output and 11-channel DSP<br>Perfect for upgrading multi-channel factory sound systems<br>Optional cable harnesses for easy integration into existing multi-channel factory sound systems<br>Extremely powerful 64 Bit “fixed point” Audio DSP<br>ACO – Advanced 32 Bit CoProcessor platform for system and DSP features like:<br>ISA (Input Signal Analyzer) and InputEQ for easy analysis and compensation of input signals<br>SFX sound effects – Augmented Bass Processing, StageXpander, RealCenter &amp; Co.<br>High power 8-channel highlevel input with ADEP.3 circuit – two channels with up to 32 V RMS input sensitivity<br>1 to 1 Input / Output Routing (IOR) in combination with the optional MEC ANA-LOG IN module – same number of highlevel inputs and amplifier outputs<br>Virtual Channel Processing (VCP) allows even more flexible configuration for highly complex sound systems<br>MATCH Extension Card slot (MEC) for additional input / output modules like Bluetooth® Audio Streaming, High Resolution Audio Streaming via USB etc.<br>Optical input in SPDIF format with sampling rate between 12 and 96 kHz<br>Mono RCA output for the connection of an external amplifier e.g. subwoofer amplifier<br>SCP (Smart Control Port) for optional accessory like WIFI CONTROL, DIRECTOR, CONDUCTOR &amp; Co.<br>Auto Remote switch<br>Start-Stop capability down to 6 Volts supply voltage<br>Compact design with low heat dissipation thanks to extraordinary efficiency</p>

      TECHNICAL DATA

      – @ 4 OhmsChannels A – H: 8 x 65 Watts
      – @ 2 Ohms-
      – @ 1 Ohm-
      – bridged @ 4 Ohms-
      – bridged @ 2 Ohms-
      – Subwoofer output @ 4 OhmsChannels I – J: 2 x 90 Watts
      – Subwoofer output @ 2 OhmsChannels I – J: 2 x 160 Watts
      Amplifier technologyClass GD
      Inputs8 x Highlevel speaker input
      1 x Optical SPDIF (12 – 96 kHz)
      1 x Remote In
      Input sensitivityChannels A – F: 4 – 16 Volts
      Channels G – H: 4 – 16 or 8 – 32 Volts
      Input impedance RCA / Cinch-
      Input impedance highlevel9 – 33 Ohms with ADEP.3
      Outputs10 x Speaker output
      1 x RCA / Cinch
      1 x Remote Out
      Output voltage RCA / Cinch3 Volts
      Frequency response20 Hz – 22,000 Hz
      DSP resolution64 Bit
      DSP power295 MHz (1.2 billion MAC operations/second)
      Sampling rate48 kHz
      DSP typeAudio signal processor
      Signal convertersA/D: BurrBrown
      D/A: BurrBrown
      Signal-to-noise ratio digital input105 dB (A-weighted)
      Signal-to-noise ratio analog input103 dB (A-weighted)
      Distortion (THD) 0.03 %
      Damping factor 100
      Operating voltage10.5 – 17 Volts (max. 5 sec. down to 6 Volts)
      Power ratingDC 12 V ⎓ 60 A max.
      Idle current500 mA
      Max. remote output current500 mA
      Fuse2 x 25 A LP-Mini-fuse (APS)
      Additional featuresClass GD technology with dynamically controlled
      power supply, 32 Bit CoProcessor, ADEP.3 circuit, Start-Stop capability, Smart Control Port, USB, MEC slot, Auto Remote switch, galvanically isolated Line Out
      Dimensions (H x W x D)46 x 145 x 163 mm /
      1.81 x 5.71 x 6.42″.

      Weight 1.85 kg
      Gamintojas

      MATCH

      Kanalų skaičius

      10

      DSP

      Taip
