<p>BMW Plug&amp;Play amplifier package makes it possible to take your OEM-system to a whole new level very easily!<br><br>This package includes Match PP86DSP amplifier and Plug&amp;Play-cable set. With this cable installation is Plug&amp;Play to replace OEM BMW Hi-Fi amplifier. You only have to add power and ground cables, evertyhing else happens Plug&amp;Play.<br><br>Amplifier has 8 output channels and 9-channel DSP and RCA-out for additional subwoofer amplifier. This is controlled via the 9th channel of DSP. You can get HD-input module or Bluetooth input module as accessories.</p>

TECHNICAL DATA

Output power RMS / max.
All channels @ 4 Ohms8 x 55 Watts / 110 Watts
All channels @ 2 Ohms8 x 70 Watts / 140 Watts
Inputs6 x Highlevel speaker input
1 x Optical SPDIF (12 – 96 kHz)
1 x Remote In
Input sensitivity5 – 11 Volts
Outputs8 x Speaker
2 x RCA / Cinch (mono)
2 x Remote Out
Output voltage RCA / Cinch3 Volts RMS
Frequency response20 Hz – 22,000 Hz
DSP resolution64 Bit
DSP power295 MHz
(1.2 billion MAC operations/second)
Sampling rate48 kHz
Signal convertersA/D: BurrBrown
D/A: BurrBrown
Signal-to-noise ratio
103 dB (A-weighted)
Distortion (THD) 0.015 %
Damping factor 100
Input impedance 13 Ohms
Operating voltage 10.5 -16 Volts (max. 5 sec. down to 6 Volts)
Max. remote output current
500 mA
Dimensions (H x W x D)44 x 185 x 164 mm ”
Additional featuresClass HD technology with dynamically controlled power supply, Start-Stop capability, Control Input, USB, MEC slot, Auto Remote switch, galvanically isolated Line Out.
