TECHNICAL DATA

Output power RMS / max.
– @ 4 Ohms 8 x 55 / 110 Watts
– @ 2 Ohms 8 x 70 / 140 Watts
– @ 1 Ohm –
– bridged @ 4 Ohms –
– bridged @ 2 Ohms –
– Subwoofer output @ 4 Ohms –
– Subwoofer output @ 2 Ohms –
Amplifier technology Class HD
Inputs 6 x Highlevel speaker input
1 x Optical SPDIF (12 – 96 kHz)
1x MEC
1 x Remote In
Input sensitivity Highlevel 5 – 11 Volts
Input impedance RCA / Cinch –
Input impedance highlevel 13 Ohms
Outputs 8 x Speaker output
2 x RCA / Cinch (mono)
2 x Remote Out
Output voltage RCA / Cinch 3 Volts RMS
Frequency response 20 Hz -22,000 Hz
DSP resolution 64 Bit
DSP power 295 MHz (1.2 billion MAC operations/second)
Sampling rate 48 kHz
DSP type Audio signal processor
Signal converters A/D: BurrBrown
D/A: BurrBrown
Signal-to-noise ratio digital input 105 dB (A-weighted)
Signal-to-noise ratio analog input 103 dB (A-weighted)
Distortion (THD) 0.015 %
Damping factor 100
Operating voltage 10.5 – 16 Volts (max. 5 sec.down to 6 Volts)
Current draw 685 mA
Max. remote output current 500 mA
Fuse 2 x 25 A LP-Mini-fuse (APS)
Additional features Class HD technology with dynamically controlled
power supply, Start-Stop capability, Control Input,
USB, MEC slot, Auto Remote switch, galvanically
isolated Line Out
Dimensions (H x W x D) 50 x 260 x 190 mm /
1.97 x 10.24 x 7.48“
