<p>The Z2c is the latest revision of the world’s ultimate competition amplifier. With this revision, the Z2c is able to make more power from lower voltage systems than its predecessor. At a 14v charging level, the Z2c is capable of an additional 1500 Watts of power when compared to the Z2b. Years of R&amp;D have gone into making this the most stable, durable, and highest output amplifier in its class. The chassis features the DD Audio exclusive HVAC heat management system. The HVAC system is designed with a recessed bottom panel heatsink, additional end plate ventilation, and an internal brushless fan. All of these features enable High Volume Air Circulation to keep your amp running cool even when it’s working crazy hard.<br><br>The chassis mounting points for the heavy duty 3oz PCB have been optimized for minimal PCB vibration, and the power devices are hand wound and hand soldered for added durability and maximum current flow. To keep up with the demand of the monstrous output section the power supply features 8 toroids and 3 x 0ga Power and Ground Inputs.<br><br>The Z2c comes with our latest VM-Remote gain control that features a digital voltage display and clipping indicator. The Z2c is also Strappable and Linkable for multi-amp connection. For the icing on the cake, all Z2c amps will be numbered sequentially with chassis engraving.</p>

TECHNICAL DATA

Test Voltage12/14/16
Channels1
Cont Wattage @ 4ohm3,900×1@14V
Cont Wattage @ 2ohm7,100×1@14V
Cont Wattage @ 1ohm8,000×1@12V, 11,500×1@14v, 14,300×1@16V
Dynamic Wattage20,000×1@16v
Max Current Draw – Amperage2000
S/N Ratio85dB
THD0.03
Input Voltage Sensitivity6 – 0.2
Pass-Through OutputYes
Remote Subwoofer ControlYes
Power Wire Guage In3 x 0
Speaker Wire Gauge Out10
Dimensions: in37 x 10.5 x 3
Dimensions: mm940 x 268 x 78.5
Shipping Weight – lbs60lbs.
