Z-150.4 AP   4 Ch. Class AB Audiophile Amplifier

Features and Functions

4-Channel, Class-AB, Competition Audiophile Amplifier

Signal to noise ratio of over 110dB

Coupled the output drivers

Highest HFE (Gain) Sanken selected output devices

Deferentially balanced input stage

0.1% resistors for lowest possible noise floor

TI LME49720 (BJT) op-amps on the inputs

BB OP2604 (JFET) op-amps in the signal path

WIMA MKS2 series caps in the signal path

Extremely low ESR caps throughout

Proprietary patented RCA connectors

Specifications

Power @ 4Ω: 4 x 150 watts

Power @ 2Ω: 4 x 250 watts

Power @ 4Ω Bridged: 2 x 500 watts

THD @ Rated Power  < 0.05% Signal to Noise Ratio > 110dB

Frequency Response 10Hz to 30,000Hz ±1dB

Input Sensitivity 1v to 9v

Dimensions in mm: 190(W) x 62(H) x 444(L) Overall: 190(W) x 62(H) x 479(L)
