MOSCONI GLADEN ATOMO 2 24V

MOSCONI GLADEN ATOMO 2 24V

MOSCONI GLADEN ATOMO 2 24V

€269.00 vnt

people are viewing this right now

Ypač mažas 2-jų kanalų 24V D klasės garso stiprintuvas

Liko vnt.

Pristatymo terminas: 1-14 d.

Image Safe Checkout

Garantuotas saugus apmokėjimas

NEMOKAMAS PRISTATYMAS LIETUVOJE UŽSAKIUS VIRŠ 99 EUR
PREKIŲ PRISTATYMAS LIETUVOJE PER 2 - 3 D.D. Shipping & Return

Kategorijos: Automobilių technika, Stiprintuvai ir jų priedai, Stiprintuvai

Aprašymas

Innovative. Efficient. Musical.

Innovations based on the Mosconi Pico line with its efficient digital technology lead to an excellent performance of the Mosconi ATOMO line.

The efficient amplifiers in mini format are ideal for the configuration of small hifi systems or as afterburners for factory radios.

An absolute marvel is the Mosconi ATOMO 6|8 DSP. This small 6 channel sound processor offers you the possibility in the simplest way to achieve an optimal sound tuning in your vehicle.

OVERVIEW MOSCONI ATOMO 2 24V

ATOMO 2 – Maximum performance in the smallest of spaces

Extremely compact, powerful 2-channel amplifier
Wide input voltage range 0.4 Vrms – 5 Vrms (low level) / 1.6 Vrms – 20 Vrms (high level)
Inputs flexibly configurable (floating / fixed ground, switchable load resistors)
Remote detection (BTL)
High pass / low pass filter. Inputs designed in Molex industry standard (Micro-Fit)
12 V and 24 V versions

TECHNICAL DATA MOSCONI ATOMO 2 24V

POWER SUPPLY:

Power supply voltage: 10 – 16 V
DC-DC converter typology: Unregulated – Push Pull
External fuse: 1 x 15 A
Power-on/Power-off voltage threshold: 9 V / 6 V
Mute delay time: 3 secs
Autosense power-on (HL only): BTL source only
Overall efficiency: > 75 %
Standby current: < 0.1 mA (typical)
Idle current: 0.47 A @ 14.4 V
Thermal cutoff threshold: 93 °C (± 5 %)

OUTPUT POWER RMS @ 14.4 V (1 % THD)

Output power RMS @ 4Ω: 100 W x 2 or 220 W x 1
Output power RMS @ 2Ω: 110 W x 2
T.H.D. @ 4Ohm: < 0.3 % (1 kHz / 90 Power rating ref)
T.H.D. @ 2Ohm: < 0.5 % (1 kHz / 90 Power rating ref)
Minimum load: 2 Ohm with musical signal

SIGNAL INPUT

Low level input sensitivity range: 0.4 ÷ 5 Vrms
High level input sensitivity range: 1.6 ÷ 20 Vrms
Bandwidth (-3dB ÷ 10W): 5 Hz ÷ 40 kHz
Low level Input impedance: > 15 kOhm
High level input impedance: 21 Ohm (dummy load with jumper)
Ground reference (LL only): OPEN – 21Ohm
S/N (AP filter 10Hz – 22KHz):

FEATURES

Onboard filter configuration: OFF – HP – LP
Onboard filter slope: 12 dB/Oct
Onboard filter frequency: 80 Hz
Autosense power-on (HL only): BTL source only
Start&Stop compliance: YES

CONNECTIONS

Low/High level input : Micro-Fit
Speaker out: Mini-Fit
Power supply: Mini-Fit

APPEARANCE

Dimensions: 86 x 65 x 34 mm
Weight: 275 g
Finishing: Black anodized

Papildoma informacija

DSP	Ne
Kanalų skaičius	2
Spalva	Juoda
