Mono Power Amplifier with remote control – MRV-M1200

Tens of thousands have relied on V-Power amplifiers for dependable, quality power. Now in their fourth generation, V-Power amplifiers carry on this heritage and prove that playing strong never looked our sounded better. Yes, it is possible to improve upon a good thing.

Product information

Proven Power

Each V-Power amplifier comes with its very own birth-sheet. V-Power amplifiers are tested and documented to show their true actual output.

Raising the Bar

The new V-Power products are now Class D digital amplifiers, resulting in a huge efficiency gain versus their predecessors without draining your battery or your pockets. Class-D provides continuous clean power to your speakers, operating at 80% efficiency far greater than conventional Class A or B amplifiers. Translation: Enjoy cleaner bass, even during extreme power demands.

Big Power, Small Package

V-Power amplifiers are known for their compact size, but don’t underestimate their power capacity. Although they have a 40% smaller footprint than their predecessors, they produce the same amount of power as before. Get the power you need, even if you have limited installation space.

Non Shut-Down Design

Even if you pound your music for a long time, these amps won’t shut down. They use a Thermal Management Processor to make sure the heat level never gets too high. No distortion, no interruptions!

Dual Feedback Modulation

Dual internal error correction technology – which had previously only been available in the PDX and X-Power amplifiers, is now integrated in V-Power mono amplifiers. The audio input signal is analysed, compared, and corrected twice dynamically as the signal is processed through the amplifier. The result is amplifiers with the widest frequency response, higher damping factor, and lowest noise in its class.

Exceptionally Simple Sound Upgrade

The V-Power’s 4-channel speaker level inputs connect directly to any head unit, without the need for external converters. This makes the V-Power amplifiers ideal for upgrading factory and aftermarket systems. The flush mount controls make for easy installation. The terminal covers conveniently snap-on without the need for additional tools, to protect the wiring connections while creating a clean, finished appearance.

Remote Bass Control included.

Use the Remote Bass Control (RUX-KNOB) to conveniently adjust bass levels from your dash.

FEATURES

Install

Terminal Layout: Two-Sided

Screw Mount / Wire Cover: Integrated Wire and Mounting Screw Terminals

General

Amplifier Type: Class-D (Digital)

Channel Design: 1 Channel (Mono)

Power Supply Design: DC-DC PWM Power Supply

Power Supply: MOSFET

Pre-Amp Stage: Discrete

Final Outputs: Power MOSFET

Crossover: Variable Lowpass Filter

Gain Control: Continuously Adjustable Gain Control

Bass EQ: Bass EQ Function

Bass Control:  Remote Bass Control (RUX-KNOB) included

Remote Turn On: Remote Sensing Function (for Speaker Level Input)

Low-impedance Possibility:

Current Protection: Over-Current, Over-Voltage, Under-Voltage and Thermal Protection

Board Circuitry: S.T.A.R. Circuit

RCA Output: Non-Fading Pre-Amp Output (4 Volts)

Speaker-Level Inputs: 4-channel Speaker Level Inputs

Power Indicator: Top Mounted Blue LED Power Indicator

Thermal Control: Multi-stage Power Limits

SPECIFICATIONS

Max Power Output Ratings

Total Max Power: 2000W

RMS Power Ratings

Per channel into 4 Ohms: 600W RMS x 1 (14.4V at <1% THD+N) Per channel into 2 Ohms: 1200W RMS x 1 (14.4V at <1% THD+N)   Sound Tuning Crossover Frequency (LPF): 50 - 400 Hz, -24dB/oct. EQ (Equalizer): 0 to +12dB, fc=50Hz   Dimensions Foot Print (WxHxD) mm: 342 x 55 x 219 mm Heat Sink (WxHxD) mm: 305 x 55 x 215 mm   General Power Requirements: 14.4 V.DC (11-16V allowable) Input Sensitivity (RCA Input): 0.15 - 4.0 V Input Sensitivity (Speaker Level Input): 0.4 - 10 V Input Impedance: >10k ohms

Frequency Response (+0, -3dB: 1W into 4 Ohms) for Subwoofer: 10 -400 Hz

THD+N (10W into 4 Ohms): ≤ 1 %

THD+N (10W into 2 Ohms): ≤ 1 %

THD+N (Rated Power into 4 Ohms): ≤ 1 %

THD+N (Rated Power into 2 Ohms): ≤ 1 %

Damping Factor (10W into 4 Ohms at 100Hz): >750

Signal to Noise (1W into 4 Ohms): >85 dB

Signal to Noise (Rated Power into 4 Ohms): >107 dB

Preamp Output: 4.0V Max.

Remote Level: -20 to 0 dB

Weight: 4.16 kg
