X800D-V – Advanced Navi Station, Alpine Style Product for Mercedes Vito (V639) and Viano (W639)
When we at Alpine set out to study the V-Class driver’s car life, we had only one goal in mind: to create a high-end infotainment system that exceeds all expectations a V-Class owner may have.
The result is a premium infotainment system that perfectly integrates into the V-Class (Viano /Vito) to bring the latest media compatibility, cutting-edge navigation technology and audiophile sound quality to your vehicle. All components are designed to fit perfectly in existing installation locations and integrate perfectly with the vehicle’s electronic systems.
Perfect vehicle integration with premium components. Performance without compromise.
FEATURES
Tuner
Memory Presets: Preset Stations (FM: 18 / MW: 6 / LW: 6)
Memory: Auto Memory
Seek Mode: Local / DX Selection
RDS
RDS Functions: AF, TA, TP, PTY, NEWS, RADIO TEXT
DAB Tuner
DAB Tuner Built-in
DAB+/DMB Supported
Service Preset: 18 Preset Memory (6 services for each band, DAB 1/2/3)
Auto Ensemble/Service Memory
RDS Fallback (where available)
Service Search Function
PTY Search Function
Antenna Power Supply Selection
DAB Antenna included
BLUETOOTH®
Built-in BLUETOOTH® Module
HFP (Hands-Free Profile) Compatible
Streaming Music: A2DP (Advanced Audio Distribution Profile) Compatible
Streaming Music Control: AVRCP (Audio / Video Remote Control Profile) Ver.1.4 Compatible
Advanced BLUETOOTH® Technology
Connection: SSP (Simple Secure Pairing) Supported
Individual Profile Connection Hands Free Phone and Music Streaming
Phone Book: Phone Book Synchronization
Speed Dial: 4 Preset Memory (per phone)
Multiple Phone Number Registration: 5 Phone Numbers can be stored for one name
Device Name Display
Auto Answer
Call History Display: Outgoing Calls / Incoming Calls / Missed Calls
Redial Function
Speech Volume Level Adjustment: Possible for Outgoing and Incoming Volume
DTMF (Touch-Tone) Function
Signal Strength Indicator
Battery Level Indicator
Menu Language Selection: 24 Languages
Firmware Updatable
Microphone Included
Made for iPod® / iPhone®
Compatibility for iPod/iPhone: Made for iPod touch 5th/4th/3rd/2nd/1st Gen., iPod nano 7th/6th/5th/4th/3rd/ Gen., iPod classic 160GB/120GB/80GB, iPod with video, iPhone5S,iPhone5C, iPhone5, iPhone 4S, iPhone 4, iPhone 3GS, iPhone 3G
Connection: KCU-461iV Required (Sold separately)
Music & Video Playback Compatible
Available Selections: Playlist / Artist / Album /Song / Podcast / Genre / Composer / Audiobook
Alphabet Search
Artwork Display
Direct Up / Down: Playlist / Artist / Album / Genre / Composer
M.I.X. (Shuffle) Play: Song, Albums, All
Repeat
Battery Charging
Disc Player
Disc Type: DVD/CD Player
Disc Playback Type: DVD-Video, CD, CD-R/RW, DVD±R/RW
Playable Format: DVD-Video, CDDA, MP3/WMA/AAC, DivX
M.I.X. Random Play
Repeat
DVD Direct Menu Control
CD Text Display
CD Text Name Search
DAC: 24 Bit DAC
Navigation Function
Map Coverage: 47 Countries (Western and Eastern Europe)
Menu Language: 29 Languages
Voice Guidance Language: 29 Languages for Voice Guidance, 15 Languages for Text-to-Speech (TTS)
Advanced Address Search
Post Code Search
Free Form Search
Partial Name Search
Advanced POI Functions
Smart Routes: Smart Routes using historic traffic patterns
Advanced Route Planning
Eco Route Search
7 Alternative Route Recommendation
Advanced TMC Mode
Map Display Mode: 2D Heading Up, 2D North Up, 3D
3D City Mode: 3D Building/Icon Display
Elevation Map Display: 3D maps with elevation mode
3D Motorway Junction View: Junction View with Sign Post
Drive Lane Suggestion
Tunnel Mode
Highway Mode
Voice Guidance Mixing
Text-to-Speech
Direct Phone Call from POI data
3 Positioning Sensors: GPS, Gyroscope, Vehicle Speed Pulse
USB Media Connection
USB Connection: USB Extension Cable Included
Music & Video Playback Compatible
Music Playback: MP3/WMA/AAC Playback
Video Playback: DivX Playback
File / Folder Name Search
Tag Info Search
Folder Up / Down
M.I.X. Random Play
Repeat
Sound Tuning
Bass Engine SQ
Bass Engine™ Pro
Subwoofer Level Adjustment
Subwoofer Phase Select
4V High Voltage PreOut
Equalizer: Flat, Pops, Rock, News, Jazz, Electrical Dance, Hip Hop, Easy Listening, Country, Classical
9-band Parametric Equalizer
6 Channel Digital Time Correction
Digital Crossover Setting
Customized Sound Setting by Car Type
MediaXpander
Application Volume Level Setting
Sound Setting Data Download
Easy, Step-by-Step Sound Customization
TuneIt ready
General
Power Output: 4 x 50 W High Power Amplifier
Advanced Power IC
Display: 8′′ WVGA High Resolution Display
White LED Backlighting System
50/50 Split Screen: Left / Right Position Changeable
Motorized Display Operation
Control Type: Touch, Drag, Flick
My Favorites Function
Automatic Setting Change for 2 Users
Display Colour Setting: Mercedes Design – Amber
High Grade Audiophile Design
PreOut: 3 PreOuts (4V, Front / Rear / Subwoofer)
AUX-Out: 1 A/V AUX Output
AUX-In: 2 A/V AUX Input
Steering Wheel Remote Control Ready
OEM Sub-display Ready
Remote Control Ready
Navigation Guidance Mix
Camera Connection & Built-in Controls for Multi-View Camers
Camera Guide Line preinstalled
Rearview Camera Display Automatic Boot-up
Simple Mode & Info Mode Display Selection
Visual EQ
Live Contrast Adjustment
Menu Language: 24 Languages (for AV / Bluetooth), 29 Languages (Navigation Menu and Voice Guidance)
Clock
Auto Dimmer
Anti-theft security code
Firmware Updatable
Power Antenna Lead
Remote Turn-On
Optical Output
HDMI Input (Alpine Special HDMI connector required)
Engine StartStop unaffected
Can Connection Interface Included
Map & Database
Online Map Update
Installation
Includes installation brackets, wiring harness, antenna adapter, CAN bus interface and DAB antenna for complete installation.
SPECIFICATIONS
Screen
Screen Size: 8 inch Wide
LCD Type: Transparent Type TN LCD
Operation System: TFT Active Matrix
Number of Picture Elements: 1,152,000 pixels (800 x 3 x 480)
Illumination System: White LED Backlighting
Effective Number of Picture Elements: 99.99%
Colour System: NTSC, PAL
Max Power Output Ratings
Max Power Output: 4 x 50 W
FM Tuner
Tuning Range: 87.5 – 108.0 MHz
Mono Usable Sensitivity: 8.1 dBf (0.7 µV / 75 ohms)
50dB Quieting Sensitivity: 12 dBf (1.1 µV / 75 ohms)
Alternate Channel Selectivity: 80 dB
Signal-to-Noise Ratio: 65 dB
Stereo Separation: 35 dB
Capture Ratio: 2 dB
MW Tuner
Tuning Range: 531 – 1,602 kHz
Usable Sensitivity (IEC Standard): 25.1 µV / 28 dBf
LW Tuner
Tuning Range: 153 – 281 kHz
Usable Sensitivity (IEC Standard): 31.6 µV / 30 dBf
Disc Player
Frequency Response: 5 -20k Hz ±1 dB
Channel Separation (at 1kHz): 85 dB
DynamicRange(at 1kHz): 95 dB
Total Harmonic Distortion (at 1kHz): 0.008%
Wow & Flutter (%WRMS): B.M.L.
Signal-to-Noise Ratio: 100 dB
Horizontal Resolution: 500 lines or greater
Video Output Level: 1 Vp-p (75 ohms)
Signal-to-Noise Ratio (Video): DVD: 60 dB
USB
USB Requirements: USB 1.1/2.0
Max. Power Consumption: 1,000 mA
USB Class: Mass Storage Class, Play From Device
File System: FAT 12/16/32
MP3 Decoding: MPEG-1/2 AUDIO Layer-3
WMA Decoding: Windows Media™ Audio
AAC Decoding: ACC-LC format ′′.m4a′′ file
DivX Decoding: ′′.divx′′, ′′.avi′′ file
Number of Channels: 2-Channel (Stereo)
Frequency Response: 5 – 20k Hz ±1 dB *Frequency Response may differ depending on the encoder software/bit rate
Total Harmonic Distortion (at 1kHz): 0.008%
DynamicRange(at 1kHz): 95 dB
Signal-to-Noise Ratio: 100 dB
Channel Separation (at 1kHz): 85 dB
GPS
GPS Antenna Type: Micro-strip Planar Aerial
Reception Frequency: 1575.42 ±1 MHz
Reception Sensitivity: -130 dB Maximum
Reception Method: Parallel 12 Channels
BLUETOOTH®
BLUETOOTH® Version: Bluetooth V2.1+EDR
Output Power: +4 dBm Max. (Power class 2)
HFP: HFP (Hands Free Profile)
HSP (Head Set Profile)
A2DP: A2DP (Advanced Audio Distribution Profile)
AVRCP: AVRCP (Audio/Video Remote Control Profile)
Sound Tuning
Subwoofer Level Adjustment: 0 to +15
Subwoofer Phase Setting: 0° or 180°
BASS ENGINE SQ: 5Mode, Level 0 to +6
HighPassFilter: 20 / 25 / 31.5 / 40 / 50 / 63 / 80 / 100 / 125 / 160 / 200 Hz
HighPassFilter (Slope): Off / -6 / -12 / -18 / -24 dB/oct.
HighPassFilter (Gain): -12 to 0 dB
LowPassFilter: 20 / 25 / 31.5 / 40 / 50 / 63 / 80 / 100 / 125 / 160 / 200 Hz
LowPassFilter (Slope): Off / -6 / -12 / -18 / -24 dB/oct.
LowPassFilter (Gain): -12 to 0 dB
Time Correction: 0.0 – 9.9ms (0.1ms step)
Parametric Equalizer (Band 1): 20 – 100 Hz
Parametric Equalizer (Band 2): 63 – 315 Hz
Parametric Equalizer (Band 3): 125 – 500 Hz
Parametric Equalizer (Band 4): 250 – 1k Hz
Parametric Equalizer (Band 5): 500 – 2k Hz
Parametric Equalizer (Band 6): 1k – 4k Hz
Parametric Equalizer (Band 7): 2k – 7.2k Hz
Parametric Equalizer (Band 8): 5.8k – 12k Hz
Parametric Equalizer (Band 9): 9k – 20k Hz
Parametric Equalizer (Gain): -7 to +7
Application Volume Level Setting: -14 to +14
General
Power Requirement: 14.4 V. DC (11-16V allowable)
Pre Output Voltage (Before Clipping): 4 V / 10k ohms
Maximum Mounting Angle: 30°
Weight: 2.9 kg
Dimensions
Fits for Mercedes Vito (V639) and Viano (W639)
Chassis Size (W x H x D) mm: 178 x 100 x 164 mm
