Helix compose i7 High-End tweeter with hand-coated silk dome and coupling volume.<br>
<br>
Helix Compose highlights best quality, excellent manufacturing and state-of-the-art sound quality.<br>
Thanks to more than 30 years of experience in research and development of audio products Helix Compose sets new standards in the car audio speaker market.<br>
<br>
Brilliant treble response<br>
Our i7 tweeter is equipped with a fine-meshed silk dome with visco-elastic Acronal coating on both sides, guaranteeing a brilliant and smooth treble response. In addition, the integration of pure lamb’s wool and dampened coupling volume enables a very low resonance frequency and allows a deep acoustic coupling.<br>
<br>
FlexMount20 – Universal meets car-specific<br>
FlexMount is a mounting system based on specially developed adapter rings, allowing the installation of COMPOSE FlexMount speakers in an almost infinite number of vehicles. Thus, the universal tweeter effortlessly becomes a vehicle-specific tweeter, that can be easily installed in the original installation position of the vehicle in an acoustically optimized way with the matching FlexMount20 adapter ring.<br>
<br>
Features:<br>
<br>
Super-wide dispersion 0.75” / 20 mm high-end silk dome tweeter with coupling volume for lowest possible resonance frequency<br>
<br>
Exceptionally lightweight and fine-meshed silk dome ensures brilliant and smooth treble response<br>
<br>
High efficient neodymium magnet for high magnetic flux linearity<br>
<br>
Integrated, dampened coupling volume allows a low crossover frequency thanks to its low resonance frequency<br>
<br>
Sturdy Aluminum housing turned from solid<br>
<br>
Compact design and various mounting options for various installation demands<br>
<br>
Mounting pods for flush mount and angle mount included in delivery<br>
<br>
Designed for the optionally available car-specific FlexMount20 adaptors which allow an acoustically optimized and professional integration in the original mounting location of the vehicle<br>
<br>
Made in Germany<br>
<br>
Mounting options:<br>
<br>
Option a: Flus mount<br>
<br>
Option b: Angle mount<br>
<br>
Option c: Professional integration with optionally available FlexMount 20 car specific adaptor ( sold separately )

TECHNICAL DATA

Size without housing:
Tweeter outer Ø 32.00
Mounting Ø 27.2mm
Mounting depth: 19mm

Impedance: 4 Ohm
DC resistance: ( Re ) 3.4 Ohm
Frequency response: 1500 Hz – 30000 Hz
Sensitivity ( SPL ): 93 dB @ 2.83V / 1m, 90 dB @ 1W / 1m
Voice coil diameter: 20mm
Cone material: Silk dome with coupling volume

Recommended crossover frequencies for the highpass:

Slope 6dB/octave│minmum crossover frequency 4000Hz

Slope 12 dB /octave│minmum crossover frequency 3000Hz

Slope 24 dB /octave│minmum crossover frequency 2500Hz

Compatibility
FlexMount20

Scope of delivery
2 x Ci7 T20FM-SC
2 x Tweeter flush mount
2 x Tweeter pod
2 x Extension cable
2 x Mounting material
