Alpine kamerų perjungimo interfeisas – KCX-C250MC

Leidžia prijungti iki trijų Alpine direct connect kamerų.

Alpine priekinio, galinio ir šoninio vaizdo kameras galėsite valdyti grotuvo jutikliniu ekranu.

Paprasčiausiai grotuvo ekrane pasirinkite kamerą.

Veikia su naujausiais Alpine grotuvais, turinčiais Direct Camera įėjimą, pavyzdžiui X801D-U ar INE-W997D.

Features

General

Enables connection for up to three Alpine cameras with Direct Camera Connection

Supports power supply for direct cameras

Supports Alpine Multiview Cameras, you can switch between up to 4 different camera views – depending on the camera: Panorama-, Back-, Corner- and Top-view.

Required for using front, rear and side cameras at once

Includes required video and power cables

Compatible with INE-W997D, X701D-A4R, X701D-A5, X701D-Q5, X801D-U, X901D-G7 (required Software: 2.xxx or higher)

Specifications

General

Input / output: 3x Input / 1x Output

Output Image: Normal image, CVBS (NTSC Video signal) 16:9 Image output for wide-screen

Image Output impedance: 75 Ohm (1Vp-p)

Power Requirement: 9.0 to 15.6 V DC

Power Consumption: Less than 0.6W (12V)

Output voltage: 6V (DC)

Operating Temperature: -30°C – +70°C

Weight Power Section: 172g (box only)

Dimensions:

Power Unit: 106 x 60 x 22mm

Power Unit Cable: 3m
